LAF-2G - LAS-2G
This flush metal wall and ceiling cover is designed for large interior joints where minimal visibility is desired. The unique panel attachment design allows for thermal expansion and disengages during a seismic event, preventing damage to surrounding walls. This cover system can be factory primed and field painted to match almost any wall or ceiling finish. Joint sizes range from 4" to 24". Contact the factory for larger sizes or custom applications.
We’re here to help.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our in-stock products, which include our most popular models and colors that are easy to buy online.
Interested in this Product?
We would love to help you! For more information and to purchase, please contact us by requesting a quote below and we will be in touch with you shortly.
We’re here to help.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our in-stock products, which include our most popular models and colors that are easy to buy online.
Finishes
View:
-
Mill
Expansion Joint Standard Finish
Performance Data
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| LAF2G-400 | 4.00" (102 mm) | 1.00" (25 mm) | 8.00" (203 mm) | 14.38" (365 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-500 | 5.00" (127 mm) | 1.00" (25 mm) | 10.00" (254 mm) | 15.38" (391 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-600 | 6.00" (152 mm) | 1.00" (25 mm) | 12.00" (305 mm) | 16.38" (416 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-700 | 7.00" (178 mm) | 1.00" (25 mm) | 14.00" (356 mm) | 17.38" (441 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-800 | 8.00" (203 mm) | 1.00" (25 mm) | 16.00" (406 mm) | 18.38" (467 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-900 | 9.00" (229 mm) | 1.00" (25 mm) | 18.00" (457 mm) | 19.38" (492 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1000 | 10.00" (254 mm) | 1.00" (25 mm) | 20.00" (508 mm) | 20.38" (518 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1100 | 11.00" (279 mm) | 1.00" (25 mm) | 22.00" (559 mm) | 21.38" (543 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1200 | 12.00" (305 mm) | 1.00" (25 mm) | 24.00" (610 mm) | 22.38" (568 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1300 | 13.00" (330 mm) | 1.00" (25 mm) | 26.00" (660 mm) | 23.38" (594 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1400 | 14.00" (356 mm) | 1.00" (25 mm) | 28.00" (711 mm) | 24.38" (619 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1500 | 15.00" (381 mm) | 1.00" (25 mm) | 30.00" (762 mm) | 25.38" (645 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1600 | 16.00" (406 mm) | 1.00" (25 mm) | 32.00" (813 mm) | 26.38" (670 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1700 | 17.00" (432 mm) | 1.00" (25 mm) | 34.00" (864 mm) | 27.38" (695 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1800 | 18.00" (457 mm) | 1.00" (25 mm) | 36.00" (914 mm) | 28.38" (721 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-1900 | 19.00" (483 mm) | 1.00" (25 mm) | 38.00" (965 mm) | 29.38" (746 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-2000 | 20.00" (508 mm) | 1.00" (25 mm) | 40.00" (1,016 mm) | 30.38" (772 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-2100 | 21.00" (533 mm) | 1.00" (25 mm) | 42.00" (1,067 mm) | 31.38" (797 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-2200 | 22.00" (559 mm) | 1.00" (25 mm) | 44.00" (1,118 mm) | 32.38" (822 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-2300 | 23.00" (584 mm) | 1.00" (25 mm) | 46.00" (1,168 mm) | 33.38" (848 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAF2G-2400 | 24.00" (610 mm) | 1.00" (25 mm) | 48.00" (1,219 mm) | 34.38" (873 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| LAFC2G-400 | 4.00" (102 mm) | 2.50" (64 mm) | 8.00" (203 mm) | 9.19" (233 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-500 | 5.00" (127 mm) | 2.50" (64 mm) | 10.00" (254 mm) | 10.19" (259 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-600 | 6.00" (152 mm) | 2.50" (64 mm) | 12.00" (305 mm) | 11.19" (284 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-700 | 7.00" (178 mm) | 2.50" (64 mm) | 14.00" (356 mm) | 12.19" (310 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-800 | 8.00" (203 mm) | 2.50" (64 mm) | 16.00" (406 mm) | 13.19" (335 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-900 | 9.00" (229 mm) | 2.50" (64 mm) | 18.00" (457 mm) | 14.19" (360 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1000 | 10.00" (254 mm) | 2.50" (64 mm) | 20.00" (508 mm) | 15.19" (386 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1100 | 11.00" (279 mm) | 2.50" (64 mm) | 22.00" (559 mm) | 16.19" (411 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1200 | 12.00" (305 mm) | 2.50" (64 mm) | 24.00" (610 mm) | 17.19" (437 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1300 | 13.00" (330 mm) | 2.50" (64 mm) | 26.00" (660 mm) | 18.19" (462 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1400 | 14.00" (356 mm) | 2.50" (64 mm) | 28.00" (711 mm) | 19.19" (487 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1500 | 15.00" (381 mm) | 2.50" (64 mm) | 30.00" (762 mm) | 20.19" (513 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1600 | 16.00" (406 mm) | 2.50" (64 mm) | 32.00" (813 mm) | 21.19" (538 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1700 | 17.00" (432 mm) | 2.50" (64 mm) | 34.00" (864 mm) | 22.19" (564 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1800 | 18.00" (457 mm) | 2.50" (64 mm) | 36.00" (914 mm) | 23.19" (589 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-1900 | 19.00" (483 mm) | 2.50" (64 mm) | 38.00" (965 mm) | 24.19" (614 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-2000 | 20.00" (508 mm) | 2.50" (64 mm) | 40.00" (1,016 mm) | 25.19" (640 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-2100 | 21.00" (533 mm) | 2.50" (64 mm) | 42.00" (1,067 mm) | 26.19" (665 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-2200 | 22.00" (559 mm) | 2.50" (64 mm) | 44.00" (1,118 mm) | 27.19" (691 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-2300 | 23.00" (584 mm) | 2.50" (64 mm) | 46.00" (1,168 mm) | 28.19" (716 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| LAFC2G-2400 | 24.00" (610 mm) | 2.50" (64 mm) | 48.00" (1,219 mm) | 29.19" (741 mm) | 5.19" (132 mm) | 0.63" (16 mm) |
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| LAS2G-400 | 4.00" (102 mm) | 1.00" (25 mm) | 8.00" (203 mm) | 11.00" (279 mm) | N/A | N/A |
| LAS2G-500 | 5.00" (127 mm) | 1.00" (25 mm) | 10.00" (254 mm) | 12.00" (305 mm) | N/A | N/A |
| LAS2G-600 | 6.00" (152 mm) | 1.00" (25 mm) | 12.00" (305 mm) | 13.00" (330 mm) | N/A | N/A |
| LAS2G-700 | 7.00" (178 mm) | 1.00" (25 mm) | 14.00" (356 mm) | 14.00" (356 mm) | N/A | N/A |
| LAS2G-800 | 8.00" (203 mm) | 1.00" (25 mm) | 16.00" (406 mm) | 15.00" (381 mm) | N/A | N/A |
| LAS2G-900 | 9.00" (229 mm) | 1.00" (25 mm) | 18.00" (457 mm) | 16.00" (406 mm) | N/A | N/A |
| LAS2G-1000 | 10.00" (254 mm) | 1.00" (25 mm) | 20.00" (508 mm) | 17.00" (432 mm) | N/A | N/A |
| LAS2G-1100 | 11.00" (279 mm) | 1.00" (25 mm) | 22.00" (559 mm) | 18.00" (457 mm) | N/A | N/A |
| LAS2G-1200 | 12.00" (305 mm) | 1.00" (25 mm) | 24.00" (610 mm) | 19.00" (483 mm) | N/A | N/A |
| LAS2G-1300 | 13.00" (330 mm) | 1.00" (25 mm) | 26.00" (660 mm) | 20.00" (508 mm) | N/A | N/A |
| LAS2G-1400 | 14.00" (356 mm) | 1.00" (25 mm) | 28.00" (711 mm) | 21.00" (533 mm) | N/A | N/A |
| LAS2G-1500 | 15.00" (381 mm) | 1.00" (25 mm) | 30.00" (762 mm) | 22.00" (559 mm) | N/A | N/A |
| LAS2G-1600 | 16.00" (406 mm) | 1.00" (25 mm) | 32.00" (813 mm) | 23.00" (584 mm) | N/A | N/A |
| LAS2G-1700 | 17.00" (432 mm) | 1.00" (25 mm) | 34.00" (864 mm) | 24.00" (610 mm) | N/A | N/A |
| LAS2G-1800 | 18.00" (457 mm) | 1.00" (25 mm) | 36.00" (914 mm) | 25.00" (635 mm) | N/A | N/A |
| LAS2G-1900 | 19.00" (483 mm) | 1.00" (25 mm) | 38.00" (965 mm) | 26.00" (660 mm) | N/A | N/A |
| LAS2G-2000 | 20.00" (508 mm) | 1.00" (25 mm) | 40.00" (1,016 mm) | 27.00" (686 mm) | N/A | N/A |
| LAS2G-2100 | 21.00" (533 mm) | 1.00" (25 mm) | 42.00" (1,067 mm) | 28.00" (711 mm) | N/A | N/A |
| LAS2G-2200 | 22.00" (559 mm) | 1.00" (25 mm) | 44.00" (1,118 mm) | 29.00" (737 mm) | N/A | N/A |
| LAS2G-2300 | 23.00" (584 mm) | 1.00" (25 mm) | 46.00" (1,168 mm) | 30.00" (762 mm) | N/A | N/A |
| LAS2G-2400 | 24.00" (610 mm) | 1.00" (25 mm) | 48.00" (1,219 mm) | 31.00" (787 mm) | N/A | N/A |
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| LASC2G-400 | 4.00" (102 mm) | 2.50" (64 mm) | 8.00" (203 mm) | 7.50" (191 mm) | N/A | N/A |
| LASC2G-500 | 5.00" (127 mm) | 2.50" (64 mm) | 10.00" (254 mm) | 8.50" (216 mm) | N/A | N/A |
| LASC2G-600 | 6.00" (152 mm) | 2.50" (64 mm) | 12.00" (305 mm) | 9.50" (241 mm) | N/A | N/A |
| LASC2G-700 | 7.00" (178 mm) | 2.50" (64 mm) | 14.00" (356 mm) | 10.50" (267 mm) | N/A | N/A |
| LASC2G-800 | 8.00" (203 mm) | 2.50" (64 mm) | 16.00" (406 mm) | 11.50" (292 mm) | N/A | N/A |
| LASC2G-900 | 9.00" (229 mm) | 2.50" (64 mm) | 18.00" (457 mm) | 12.50" (318 mm) | N/A | N/A |
| LASC2G-1000 | 10.00" (254 mm) | 2.50" (64 mm) | 20.00" (508 mm) | 13.50" (343 mm) | N/A | N/A |
| LASC2G-1100 | 11.00" (279 mm) | 2.50" (64 mm) | 22.00" (559 mm) | 14.50" (368 mm) | N/A | N/A |
| LASC2G-1200 | 12.00" (305 mm) | 2.50" (64 mm) | 24.00" (610 mm) | 15.50" (394 mm) | N/A | N/A |
| LASC2G-1300 | 13.00" (330 mm) | 2.50" (64 mm) | 26.00" (660 mm) | 16.50" (419 mm) | N/A | N/A |
| LASC2G-1400 | 14.00" (356 mm) | 2.50" (64 mm) | 28.00" (711 mm) | 17.50" (445 mm) | N/A | N/A |
| LASC2G-1500 | 15.00" (381 mm) | 2.50" (64 mm) | 30.00" (762 mm) | 18.50" (470 mm) | N/A | N/A |
| LASC2G-1600 | 16.00" (406 mm) | 2.50" (64 mm) | 32.00" (813 mm) | 19.50" (495 mm) | N/A | N/A |
| LASC2G-1700 | 17.00" (432 mm) | 2.50" (64 mm) | 34.00" (864 mm) | 20.50" (521 mm) | N/A | N/A |
| LASC2G-1800 | 18.00" (457 mm) | 2.50" (64 mm) | 36.00" (914 mm) | 21.50" (546 mm) | N/A | N/A |
| LASC2G-1900 | 19.00" (483 mm) | 2.50" (64 mm) | 38.00" (965 mm) | 22.50" (572 mm) | N/A | N/A |
| LASC2G-2000 | 20.00" (508 mm) | 2.50" (64 mm) | 40.00" (1,016 mm) | 23.50" (597 mm) | N/A | N/A |
| LASC2G-2100 | 21.00" (533 mm) | 2.50" (64 mm) | 42.00" (1,067 mm) | 24.50" (622 mm) | N/A | N/A |
| LASC2G-2200 | 22.00" (559 mm) | 2.50" (64 mm) | 44.00" (1,118 mm) | 25.50" (648 mm) | N/A | N/A |
| LASC2G-2300 | 23.00" (584 mm) | 2.50" (64 mm) | 46.00" (1,168 mm) | 26.50" (673 mm) | N/A | N/A |
| LASC2G-2400 | 24.00" (610 mm) | 2.50" (64 mm) | 48.00" (1,219 mm) | 27.50" (699 mm) | N/A | N/A |
