Buy Now
SF (2"-7")
We’re here to help.
Want assistance? It's easy to get in touch with us - use one of the buttons below.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our Standard Products, which include a selection of materials for quick and easy online purchases.
Interested in this Product?
You’re in luck - this product is available to purchase online. Click below to buy.
If you have questions or would like additional information, contact us by requesting a quote below and we will get in touch with you shortly. Additional finishes and colors are available, request a quote if your preferred color is not available to buy online.
We’re here to help.
Want assistance? It's easy to get in touch with us - use one of the buttons below.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our Standard Products, which include a selection of materials for quick and easy online purchases.
Finishes
-
#232 White
-
#270 Greige
-
#136 Gray
-
#108 Black
-
#764 Platinum
Gasket Colors
-
Mill
Expansion Joint Standard Finish
Performance Data
| Model | Joint Width | Min. Opening | Max. Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| SF-200 | 2.00" (51mm) | 1.25" (32mm) | 3.00" (76mm) | 2.00" (51mm) | N/A | N/A |
| SF-300 | 3.00" (76mm) | 1.25" (32mm) | 4.50" (114mm) | 3.00" (76mm) | N/A | N/A |
| SF-400 | 4.00" (102mm) | 1.25" (32mm) | 6.00" (152mm) | 4.00" (102mm) | N/A | N/A |
| SF-500 | 5.00" (127mm) | 1.25" (32mm) | 7.50" (191mm) | 5.00" (127mm) | N/A | N/A |
| SF-600 | 6.00" (152mm) | 1.75" (44mm) | 9.00" (229mm) | 6.00" (152mm) | N/A | N/A |
| Model | Joint Width | Min. Opening | Max. Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| SF-700 | 7.00" (178mm) | 2.50" (64mm) | 10.50" (267mm) | 7.00" (178mm) | N/A | N/A |
| SF-800 | 8.00" (203mm) | 2.50" (64mm) | 12.00" (305mm) | 8.00" (203mm) | N/A | N/A |
| SF-900 | 9.00" (229mm) | 2.50" (64mm) | 13.50" (343mm) | 9.00" (229mm) | N/A | N/A |
| SF-1000 | 10.00" (254mm) | 2.50" (64mm) | 15.00" (381mm) | 10.00" (254mm) | N/A | N/A |
