VF
This impregnated, compressible foam block is for exterior applications and provides a weather-tight, airtight, UV-stable, and insulated primary seal. Once the joint sealant is installed, the material expands and adapts to the width of the joint opening. This cover is available in a variety of standard colors and is supplied in 6'6" lengths. (Note: VF-100 is supplied in 10' reel length). Joint sizes range from 1" to 8". Contact the factory for larger sizes or custom applications.
We’re here to help.
Want assistance? It's easy to get in touch with us - use one of the buttons below.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our Standard Products, which include a selection of materials for quick and easy online purchases.
Interested in this Product?
We would love to help you! For more information and to purchase, please contact us by requesting a quote below and we will be in touch with you shortly.
We’re here to help.
Want assistance? It's easy to get in touch with us - use one of the buttons below.
Many of our product solutions offer choices for customization, and we would love to talk you through your options. Also consider checking out our Standard Products, which include a selection of materials for quick and easy online purchases.
Finishes
-
White
-
Light Gray
-
Charcoal
-
Black
-
Limestone
-
Deck Gray
-
Beige
-
Sandstone
-
Colonial White
-
Adobe Tan
-
Quarry Red
Silicone Building Sealant (VF and VFR Colors)
Performance Data
| Model | Joint Width | Min. Opening | Max. Opening | Exposed Surface | Blockout Width | Blockout Height | Seal Depth |
|---|---|---|---|---|---|---|---|
| VF-100* | 1.00" (25mm) | 0.50" (13mm) | 1.50" (38mm) | 1.00" (25mm) | N/A | N/A | 1.75" (44mm) |
| VF-150 | 1.50" (38mm) | 0.75" (19mm) | 2.25" (57mm) | 1.50" (38mm) | N/A | N/A | 2.25" (57mm) |
| VF-200 | 2.00" (51mm) | 1.00" (25mm) | 3.00" (76mm) | 2.00" (51mm) | N/A | N/A | 2.50" (64mm) |
| VF-250 | 2.50" (64mm) | 1.25" (32mm) | 3.75" (95mm) | 2.50" (64mm) | N/A | N/A | 2.75" (70mm) |
| VF-300 | 3.00" (76mm) | 1.50" (38mm) | 4.50" (114mm) | 3.00" (76mm) | N/A | N/A | 3.50" (89mm) |
| VF-350 | 3.50" (89mm) | 1.75" (44mm) | 5.25" (133mm) | 3.50" (89mm) | N/A | N/A | 3.75" (95mm) |
| VF-400 | 4.00" (102mm) | 2.00" (51mm) | 6.00" (152mm) | 4.00" (102mm) | N/A | N/A | 4.50" (114mm) |
| VF-450 | 4.50" (114mm) | 2.25" (57mm) | 6.75" (171mm) | 4.50" (114mm) | N/A | N/A | 5.00" (127mm) |
| VF-500 | 5.00" (127mm) | 2.50" (64mm) | 7.50" (191mm) | 5.00" (127mm) | N/A | N/A | 5.50" (140mm) |
| VF-550 | 5.50" (140mm) | 2.75" (70mm) | 8.25" (210mm) | 5.50" (140mm) | N/A | N/A | 5.75" (146mm) |
| VF-600 | 6.00" (152mm) | 3.00" (76mm) | 9.00" (229mm) | 6.00" (152mm) | N/A | N/A | 6.00" (152mm) |
| VF-650 | 6.50" (165mm) | 3.25" (83mm) | 9.75" (248mm) | 6.50" (165mm) | N/A | N/A | 6.50" (165mm) |
| VF-700 | 7.00" (178mm) | 3.50" (89mm) | 10.50" (267mm) | 7.00" (178mm) | N/A | N/A | 7.00" (178mm) |
| VF-750 | 7.50" (191mm) | 3.75" (95mm) | 11.25" (286mm) | 7.50" (191mm) | N/A | N/A | 7.50" (191mm) |
| VF-800 | 8.00" (203mm) | 4.00" (102mm) | 12.00" (305mm) | 8.00" (203mm) | N/A | N/A | 8.00" (203mm) |
